CIDR and Subnetting Explained: A Practical Guide for Cloud Engineers

What CIDR Replaced

Before 1993, IP addresses were allocated in rigid classes: Class A (8-bit network), Class B (16-bit), Class C (24-bit). You could have 256 hosts or 65,536 hosts — nothing in between. That worked for a few research networks. It was ruinous at internet scale: organisations that needed 400 addresses got a Class B with 65,000 and wasted the rest.

CIDR — Classless Inter-Domain Routing, RFC 4632 — dropped the fixed boundaries and let any prefix length from /1 to /32 define a network. 10.0.0.0/24 means "the first 24 bits are the network, the last 8 are hosts." Changing the prefix changes the subnet size:

The formula: a /N has 2^(32 − N) addresses.

You can confirm any of these — netmask, first/last address, host count — with the IP CIDR Calculator.

Private Ranges You Should Memorise

RFC 1918 reserves three ranges for private networks. Every VPC, home router, and corporate LAN lives inside these:

• 10.0.0.0/8 — 16.7M addresses
• 172.16.0.0/12 — 1M addresses
• 192.168.0.0/16 — 65K addresses

Public routing equipment will drop packets addressed to these ranges, which is exactly the point. Inside your VPC you can slice them however you like.

A fourth range worth knowing: 100.64.0.0/10 (RFC 6598, "carrier-grade NAT"). Some cloud providers use it for internal services; avoid it for your own networks unless you have a specific reason.

How to Plan a VPC

The common mistake is picking your VPC range too small and running out of subnet room six months in. AWS VPCs can't be resized after creation; you'd have to rebuild.

Pick your VPC at /16 unless you have a hard reason not to. That gives you 65,536 addresses and room for dozens of subnets.

Pick your subnets at /24 by default. 256 addresses per subnet is generous for most workloads and leaves routing tables readable. Going smaller (/28, /27) saves address space but creates operational pain when one subnet fills up. Going bigger (/20) limits how many availability zones you can spread across.

Example layout for a three-AZ VPC at 10.0.0.0/16:

10.0.0.0/16       VPC
├── 10.0.0.0/24   Public subnet AZ-a    (ALB, NAT gateway)
├── 10.0.1.0/24   Public subnet AZ-b
├── 10.0.2.0/24   Public subnet AZ-c
├── 10.0.10.0/24  Private app subnet AZ-a
├── 10.0.11.0/24  Private app subnet AZ-b
├── 10.0.12.0/24  Private app subnet AZ-c
├── 10.0.20.0/24  Private DB subnet AZ-a
└── ...

Gap the subnet numbers (0–9 public, 10–19 app, 20–29 db) so you can insert new tiers later without renumbering.

The Cloud-Specific Gotchas

AWS reserves 5 IPs per subnet. A /28 has 16 total addresses, but AWS reserves .0 (network), .1 (VPC router), .2 (DNS resolver), .3 (future use), and .15 (broadcast). That leaves 11 usable. A /28 subnet is usually too small for anything real — /27 is the practical minimum.

GCP reserves 4 IPs per subnet. Similar idea, different count. Check your provider's docs.

VPC peering requires non-overlapping ranges. If VPC A is 10.0.0.0/16 and VPC B is 10.0.0.0/16, you cannot peer them. Plan for this up front — if you run multiple VPCs, give each a distinct /16 out of 10.0.0.0/8: 10.0.0.0/16, 10.1.0.0/16, 10.2.0.0/16.

VPN to on-prem. If your on-prem network uses 192.168.0.0/24, avoid that range in your VPC. Routing conflicts will break connectivity in both directions.

Reading a CIDR Quickly

Two tricks that make CIDR math instant without a calculator:

Host count. 32 − prefix = bits for hosts. /20 → 12 host bits → 2^12 = 4,096 addresses.

Aggregation. 10.0.0.0/24 and 10.0.1.0/24 both fit inside 10.0.0.0/23. Whenever two adjacent subnets share the same prefix one bit shorter, you can summarise them. Useful when writing route tables or firewall rules.

Is an address inside a CIDR? Compare the prefix bits. 10.0.5.17 inside 10.0.0.0/16? The first 16 bits of 10.0.5.17 are 10.0, same as the CIDR — yes. Inside 10.0.0.0/24? First 24 bits are 10.0.5, CIDR's first 24 are 10.0.0 — no.

The IP CIDR Calculator checks any of these in one click.

IPv6 Uses the Same Notation

IPv6 prefixes work identically, just with longer addresses: 2001:db8::/32. The numbers get absurd — a /64 contains 2^64 addresses, more than the entire IPv4 space squared — but the mental model is unchanged. A typical LAN is /64; a site allocation from an ISP is usually /48 or /56.

Special Prefixes Worth Knowing

• 0.0.0.0/0 — "everything." Used in route tables as the default route.
• 127.0.0.0/8 — loopback. 127.0.0.1 is just the most famous member.
• 169.254.0.0/16 — link-local. If your laptop shows an address in this range, DHCP failed.
• /32 on a route — a specific host, not a network. Common in BGP.
• /31 — a special-case point-to-point link (RFC 3021), 2 usable addresses instead of 0.

Try It Now

Plug any CIDR into the IP CIDR Calculator to see the netmask, first and last addresses, total count, and usable count (with cloud-reserved IPs accounted for). Great for sanity-checking a VPC layout before you commit it to Terraform.
